This tipping counter made of polycarbonate, with a tipping scale volume of 0.1 l, is particularly well suited for recording small flow rates and can be used for volume flows from 0 to 5 l/min. It offers a low-cost alternative to the V2A tipping counters but is just as weather-resistant. In addition, in contrast to the V2A tipping counter, it is food-safe and can therefore also be used in drinking water. Our built-in membranes are made of high-quality silicone, as are all other sealing parts. The polycarbonate tipping counter can be delivered with wall holder or with base holder on request.

At each tilt, a pulse signal is triggered via a REED sensor. Based on the number of these drains, the REED sensor measures the amount of water drained. The REED sensor can be connected to an electronic counter or data logger, for example. For single units, a 1-channel data logger (e.g., Easylog) is recommended.

Per tipping, 1 % quantity aliquot can be filled into a PE collection bottle with the associated sampler for further analysis in the laboratory.
